Custom-Shape Recessed Manhole Cover – Unlimited Design Possibilities

Product Introduction

The Custom-Shape Recessed Manhole Cover breaks away from standard squares and rectangles. Designed for projects where ground geometry is curved, irregular, or architecturally expressive, this solution provides an invisible access cover in virtually any two-dimensional shape – circles, ellipses, arcs, trapezoids, polygons, sweeping organic curves, or even logos and emblems.

The split-type structure is retained: a precisely fabricated support frame (stainless steel, galvanised steel, or aluminium) follows the required perimeter, while the recessed lid is shaped identically and filled with matching ground material or left with custom engraving / branding. From heritage plazas with radial paving to modern art installations with bespoke cover patterns, our engineering team turns unique shapes into fully functional, load-rated access covers. This page showcases a selection of what we have already made – and a glimpse of what is possible for your next project.

Typical Applications (Custom Shapes)

Radial paving layouts around fountains, monuments, or circular planters (round or segmental covers)
Curved building edges and arched entrance forecourts (elliptical / parabolic shapes)
Branded manhole covers for corporate headquarters, luxury hotels, or retail plazas (logo cut-out or engraved infill)
Heritage restorations requiring period-correct octagonal or scalloped covers
Landscape islands and winding footpaths (free-form organic perimeters)
Museum and gallery floors where the cover must follow irregular stone inlays
Themed environments (amusement parks, zoos, botanical gardens) with animal-shaped or leaf-shaped covers

CALL US +852 51325069

Unlimited Geometry

Architectural Integration

One-Off to Series Production

Customisation Showcase – What We Have Made

Design Type	Description	Key Custom Feature
Circular recessed cover	Ø800mm clear opening, SS316 frame, concrete infill with radial brushed stainless dividers to match plaza paving pattern.	Integrated paving divider lines in the lid.
Elliptical drainage cover	1200×600mm ellipse, slotted lid with 8mm slots, B125 rated, installed in a curved pool deck.	Curve-matched perimeter with silicone gasket.
Octagonal heritage cover	Hot-dip galvanised frame, octagon 900mm across flats, infilled with reclaimed brick slips.	Period bolts and lifting eyes hidden under brick.
Corporate logo cover	Laser-cut scalloped shape, brushed SS304 lid with raised logo (company crest) powder coated in bronze.	Logo is part of the infill mould – then infilled with clear resin over coloured aggregate.
Organic leaf-shaped cover	3 m long “ginkgo leaf” profile, aluminium frame, open slots as “leaf veins”, installed in a botanical garden.	Vein slots double as drainage and artistic feature.
Trapezoidal multiple covers	Set of 5 trapezoidal lids forming a curved driveway apron, each D400 rated, with continuous stainless steel hinge line.	Hinged sector covers that open together as one assembly.
Art Deco fan cover	180° fan shape, 1500mm radius, brass-infused stainless steel lid with engraved geometric pattern and stone infill.	Engraving depth controlled to retain infill bonding.

What Can Be Customised – Unlimited Parameters

Shape geometry: Any closed polygon (3 to 20+ sides), circle, ellipse, sector, arc-ended rectangle, free-form curve (DXF or DWG input), symmetrical or asymmetrical.
Size range: Minimum 200mm clear span – maximum 2500mm in any dimension. Larger shapes are possible by segmenting (multi-panel interlocking covers).
Frame & lid material: Stainless steel 304 / 316, hot-dip galvanised mild steel, aluminium 6061, or duplex / Corten on request.
Material thickness: 1.5mm up to 8.0mm, selected based on load rating and shape geometry.
Load rating: A15, B125, C250, D400 (EN124/DIN or custom client standard). Even curved shapes can be engineered to pass D400 proof load testing.
Infill type: Concrete, resin-bound gravel, natural stone veneer, pavers, glass beads, LED-embedded translucent resin (for illuminated logos).
Surface detailing: Engraved text, raised or recessed logos, radial score lines, non-slip pattern, colour powder coating, brushed directional finish.
Drainage integration: Fully solid (no drainage), slotted pattern following shape contours, perforated zones limited to certain areas, or no slots at all.
Lifting mechanism: Concealed keyholes (penta / triangle), flush pull rings, magnetic lifting points, or remote release pins for security covers.
Hinge system: Free-lift split type, or heavy-duty hinge on one side (for safety or ease of use).
Edge detailing: Chamfered, radiused, or knife-edge rim to match stone coping.

Key Benefits of Our Custom-Shape Service

Shape-matched structural engineering

We analyse stress distribution around curved perimeters, adding hidden ribs or local thickening where needed. The result: a cover that fits perfectly and performs like a standard square cover – even under traffic.

No minimum order quantity for one-off shapes

Single prototype covers are welcome. For heritage or boutique projects, we make exactly what you need, not what is stocked.

Digital verification before production

We provide 3D laser scanning or CAD verification, including a dry-assembly video for complex multi-piece sets. You see the cover in virtual space before metal is cut.

Same infill + concealment principle

Despite any external shape, the recessed lid still accepts pavement material, making the cover invisible when finished. Only the shape follows your ground design.

Full testing & certification

Load testing can be witnessed at our facility. We provide EN124 certification reports for custom shapes that pass the relevant test regime.

Examples of Past Projects (Visual Concepts)

Circular plaza covers (Dublin, Ireland) – 24 circular recessed covers, 750mm diameter, laid into a radial limestone pavement. Each lid infilled with the same limestone setts; invisible from 3 metres.
Curved driveway edge (Melbourne, Australia) – A 4-metre long “banana” shaped cover following a garden kerb. Split into two hinged sections for easy pit access.
Branded hotel entrance (Singapore) – Five elliptical covers with raised hotel logo, filled with black epoxy resin and LED strip lighting around the logo outline.
Zoo animal footprint covers (Ohio, USA) – Six covers shaped like giant animal paw prints, slotted for drainage, installed in a zoo walkway. Children loved spotting them.
Heritage octagonal set (York, UK) – Four octagonal covers (600mm across), galvanised frame with brass lifters to match Victorian street furniture.

One-Stop Customisation – From Sketch to Installed Cover

We do not just take orders – we co-design. Send a hand sketch, a photo, an architectural drawing, or a 3D model.
Our engineers will advise on material selection, load rating feasibility, and manufacturing method (laser cutting, robotic welding, press forming).
We produce samples, refine the fit, and deliver final covers with installation guides. For recurring shapes, we can keep a digital file on hand for future reorders.
There is no shape too unusual, no detail too fine. The only limit is the pit opening below – and we can often advise on modifying that too.
